Air Oil Separator Filter for Excavators and Industrial Compressors
Our air oil separator filters are engineered to deliver clean, oil-free compressed air for excavators, compressors, and industrial equipment. With high-efficiency filtration media and durable construction, they effectively remove oil mist, reduce wear on downstream components, and extend service intervals—making them a critical part of any high-performance system.
| Type | Air Oil Separator Filter |
|---|---|
| Filtration Efficiency | More Than 99.9 % |
| Activated Carbon Filter Type | Compact |
| MOQ | 12 Pieces |
Quick Quote Request
Kinton Parts is trusted by professionals worldwide for delivering high-quality parts for excavators, bulldozers, and other construction machinery—with guaranteed performance and durability.
The air oil separator filter is an essential filtration component used in air compressors and hydraulic systems to remove oil aerosols from compressed air. By preventing oil carryover, it protects downstream components such as pneumatic valves, actuators, sensors, and air tools. In excavators, it ensures hydraulic air intake remains clean and dry, safeguarding the integrity of engine and hydraulic systems in challenging jobsite environments.
Filtration Principle
The air oil separator operates on the principle of coalescence and centrifugal separation. Oil-laden air enters the filter, where fine fibers in the filtration media trap and coalesce oil droplets. These larger droplets then drain to the bottom of the filter housing and are returned to the compressor or oil circuit. The cleaned, oil-free air exits through the outlet side for safe use in pneumatic or combustion systems.
Key Features & Advantages
- High Separation Efficiency: Removes 99.9% of oil particles down to 0.1 μm, ensuring superior air quality.
- Low Pressure Drop: Engineered for energy-saving operation with minimal flow resistance.
- Wide Compatibility: Suitable for screw-type compressors, diesel engines, and various excavator models.
- Durable Design: Anti-corrosive steel or aluminum shell with reinforced mesh for impact resistance.
- Temperature & Pressure Tolerance: Performs under pressures up to 16 bar and temperatures up to 120°C.
Technical Specifications
| Parameter | Value |
|---|---|
| Filtration Rating | ≤ 0.1 micron |
| Oil Removal Efficiency | ≥ 99.9% |
| Operating Pressure Range | 0–16 bar |
| Operating Temperature Range | -20°C to +120°C |
| Recommended Replacement Cycle | 2,000–3,000 hours (or per spec) |
| Material Options | Microglass, Fiberglass, Stainless Steel |
Custom specifications available upon request.
Quality Control & Testing
All air oil separator filters are subjected to a strict multi-stage quality inspection process:
- Material Verification: Incoming microglass and mesh materials are inspected for compliance with standard thickness, pore size, and chemical resistance.
- Filtration Efficiency Test: Each production batch is tested under controlled airflow to verify particle removal and saturation limits.
- Pressure Endurance Test: Filters are tested at rated max pressure to ensure casing integrity and seal performance.
- Seal Tightness Test: All seals and joints undergo leakage testing under variable pressure conditions.
Common Applications
- Air Compressors (rotary screw, piston-type)
- Diesel Engine Crankcase Ventilation
- Excavator Hydraulic Breather Systems
- Industrial Pneumatic Networks
- Construction Equipment Oil Mist Control
OEM Replacement Support
Our air oil separator filters are available as direct-fit replacements for a wide range of brands and part numbers. We support OEM customization and labeling upon request.
Common compatible brands include:
- Atlas Copco
- Kaeser
- Sullair
- Ingersoll Rand
- Doosan
- Caterpillar
- Hitachi
| Part Numbers | |||||||
|---|---|---|---|---|---|---|---|
| 0532140159 | 10525274 | 14524761 | 1614437300 | 22219174 | 2658374918 | 2901196300 | 2911001600 |
| 2911001700 | 331001000467 | 46652735 | 54749247 | 6.3569.0 | 6.3571.0 | 6.3669.0 | 88290019-362 |
| P601886 | VP1098908 | ||||||
Please provide part number or equipment model for accurate matching.
Installation & Maintenance Guide
- Ensure the system is fully depressurized before removing the old filter.
- Clean the housing and check for residual oil or contamination before installing the new filter.
- Verify that gaskets and seals are correctly aligned.
- Monitor differential pressure regularly to determine optimal replacement timing.
- Replace the filter every 2,000–3,000 hours or sooner in high-dust/oil-load environments.
Packaging & Logistics
Each filter is packed in:
- Individual protective packaging (foam or molded insert)
- OEM-labeled boxes (optional)
- Export-standard palletized cartons for bulk orders
working days; customized orders may vary based on specification and quantity.
Purchasing Tips
- Always match filter specifications (diameter, length, filtration rating, thread size) with your compressor or equipment model.
- Choose filters with verified lab performance data if used in high-value industrial setups.
- For excavators operating in dusty or humid environments, consider filters with hydrophobic coatings or enhanced drainage designs.
- Bulk orders benefit from reduced per-unit cost and better logistics efficiency.
