Undercarriage Parts Sprocket for Komatsu PC120-5
Engineered for Komatsu PC120-5 excavators, this drive sprocket ensures efficient power transmission and precise track engagement. Made from high-strength alloy steel with heat-treated teeth for extended wear life in tough working conditions.
| Material | 50Mn/40MnB |
|---|---|
| Surface Hardness | HRC53-58,deepth: 8-12mm |
| Colors | Black or yellow or customized |
Quick Quote Request
Kinton Parts is trusted by professionals worldwide for delivering high-quality parts for excavators, bulldozers, and other construction machinery—with guaranteed performance and durability.
Precision-Forged Komatsu PC120-5 Sprocket
This sprocket is specifically designed for Komatsu PC120-5 excavators, ensuring optimal fit and torque transfer across heavy-duty applications. Its tooth profile is carefully engineered to mesh perfectly with the track link, providing efficient power transmission and longer undercarriage life.
High-Quality Steel and Advanced Heat Treatment
The sprocket is made from premium-grade alloy steel such as 35Mn or 40Mn, known for its excellent hardness and wear resistance. After forging, it undergoes quenching and tempering heat treatment to reach optimal surface hardness (HRC 52-58) while maintaining a tough inner core. This combination ensures resistance to abrasion, chipping, and deformation under continuous stress.
Manufacturing Process Summary for PC120-5 Sprocket
Our production process integrates precision CNC machining, gear hobbing, tooth grinding, and strict quality control to guarantee reliable performance and dimensional accuracy.
Tooth Rough Machining
The sprocket blank is machined on a CNC lathe or gear hobbing machine to form the basic tooth profile.
Inner Ring Installation & Precision Machining
The inner ring is inserted and the entire part is precisely machined to ensure concentricity and dimensional accuracy.
Drilling
Mounting and lubrication holes are drilled to meet the installation and functional requirements.
Tooth Grinding & Finishing
After heat treatment, the sprocket teeth are ground or polished to remove burrs and ensure smooth engagement.
Surface Cleaning
The sprocket undergoes surface cleaning, removing scale and residue, preparing it for surface treatment.
Painting & Final Coating
The sprocket is coated with durable industrial paint (available in various colors), providing corrosion resistance and a clean, professional appearance.
Each sprocket undergoes rough tooth shaping, inner ring machining, drilling, finishing treatment, and painting. These steps ensure a smooth tooth profile, precise alignment, and strong anti-corrosion protection—resulting in a ready-to-install product built for endurance.
OEM Undercarriage Parts for Komatsu
| BRAND | MACHINERY MODEL NUMBER | |||||||
|---|---|---|---|---|---|---|---|---|
| KOMATSU-PC | PC20 | PC30-5 | PC30-6 | PC30-7 | PC30-8 | PC35 | PC40 | PC45 |
| PC50 | PC55 | PC40-5 | PC40-6 | PC40-7 | PC50 | PC55 | PC60-1 | |
| PC60-3 | PC60-5 | PC60-6 | PC60-7 | PC75 | PC100-1 | PC100-3 | PC100-5 | |
| PC100-6 | PC100-7 | PC120-3 | PC120-5 | PC120-6 | PC120-7 | PC150 | PC200-1 | |
| PC200-3 | PC200-5 | PC200-6 | PC200-7 | PC200-8 | PC220-1 | PC220-3 | PC220-5 | |
| PC220-6 | PC220-7 | PC220-8 | PC200LC-3 | PC200LC-5 | PC200LC-6 | PC200LC-7 | PC200LC-8 | |
| PC240 | PC300-1 | PC300-5 | PC300-6 | PC300-7 | PC300LC | PC300LC-5 | PC300LC-6 | |
| PC300LC-7 | PC360-5 | PC360-6 | PC360-7 | PC360LC-5 | PC360LC-6 | PC360LC-7 | PC360LC-8 | |
| PC400-1 | PC400-3 | PC400-5 | PC400-6 | PC400-7 | PC400LC-1 | PC400LC-3 | PC400LC-5 | |
| PC400LC-6 | PC400LC-7 | PC450-5 | PC450-6 | PC450-7 | PC450LC-5 | PC450LC-6 | PC450LC-7 | |
| PC650 | PC750 | PC800 | PC350 | |||||
Looking for a specific make or model not listed here? Reach out and we’ll be happy to assist.
Strict Dimensional and Quality Inspection
Every PC120-5 sprocket is tested for concentricity, tooth spacing, hardness distribution, and surface finish. This rigorous inspection ensures consistent quality that meets or exceeds OEM standards. Our factory also performs dynamic fit testing with actual chains to verify performance under real-world conditions.
Compatible Komatsu Models
This sprocket is fully compatible with:
Komatsu PC120-5 / PC120-6 / PC120LC-6
Other models with similar undercarriage structure and frame mounting dimensions
Please verify fitment by serial number or request drawing confirmation before purchase
Application Scenarios in Harsh Working Conditions
Ideal for construction sites, urban foundation excavation, and light to medium quarry work. The PC120-5 sprocket’s hardened teeth and structural integrity make it suitable for long-term operation in dirt, rock, and gravel environments without frequent replacements.
Maintenance Tips for Longer Service Life
To maximize the lifespan of your drive sprocket:
- Regularly inspect tooth wear and pitch alignment with the track links.
- Keep the undercarriage clean to prevent mud or gravel accumulation.
- Lubricate related components and ensure proper track tension.
- Replace worn chains in time to prevent accelerated sprocket damage.
Installation and Maintenance Best Practices
Proper installation and maintenance are key to maximizing sprocket life:
- Clean the hub area before installation
- Ensure correct bolt torque to avoid misalignment
- Check chain tension periodically
- Replace worn track links in time to avoid premature sprocket damage
Following these guidelines helps avoid excessive noise, uneven wear, or tooth skipping during operation.
